LIBERO CE
LIBERO CE
LIBERO CE
LIBERO CE
Regular priceCHF251.60
/

Application
Calibration


  • BLE PDF Logger for external Pt100 Probes
  • M8 Probe Connector
  • No Equipment required and no Software needed
  • Read Data via PDF Report
  • 100% IATA Compliant
  • Probe not included
  • Note: Manufacturer Calibration Only!



    Type: PDF Logger with USB interface for external Pt100 temperature probe (probe not included)
    Application Area: Site Monitoring, Container Monitoring, Cryo Container Monitoring, Dry-ice Container Monitoring
    Recording Options and Mode: Multiple use: start/stop or loop mode
    Type of Probe: Pt100 probe (4-wire measuring technique), max. cable length 3 m (118.1 inch), requires M8 connector
    Measurement Range:
    • Measurement range (depending on probe):
    • -200 °C..+400 °C
    • Operating range of data logger:
    • -30 °C..+70 °C
    Measurement Accuracy: System accuracy*:
    •  ±1.4 °C in the range of -200.0 °C..-100.1 °C (Class B)
    • ±1.0 °C in the range of -100.0 °C..-50.1 °C (Class B)
    • ±0.4 °C in the range of -50.0 °C..-10.1 °C (Class A)
    • ±0.3 °C in the range of -10.0 °C..+25.0 °C (Class A)
    • ±0.5 °C in the range of +25.1 °C..+100.0 °C (Class A)
    • ±0.7 °C in the range of +100.1 °C..+200.0 °C (Class A)
    • ±1.1 °C in the range of +200.1 °C..+400.0 °C (Class A)
    • *Includes data logger and external Pt100 probe of stated class
    Measurement Interval: 1 to 60 minutes, user configurable
    Measurement Capacity: 75’500 measurement values (equals logging duration of 17 months at 10 minute logging interval)
    Certificate: Certificate available via compliance.elpro.com Optional: Additional customer-specific calibration points according to ISO 17025 standard
    Case | Dimension | Weight: ABS plastic material | 95 × 41 × 11 mm (3.74 x 1.61 x 0.43 inch), cable tail 85 mm (3.35 inch) including M8 connector | 44 g (0.1 lb) | IP54
    Conformity: CE | FCC | RoHS | Safe Transport of Chemical Goods | WEEE
    Standards: RTCA DO-160 | GAMP5

    Technical Specification LIBERO CE
    • Cryo-Lid Installation for LN2 Tank is available on request!
